Performance
No need to worry about where your samples are stored within the freezer. With peak variation less than 5°C, your samples are protected and safely stored throughout the entire cabinet space. *
Long warm-up time from -50°C to -80°C: 5.05 hours*
Quiet enough to reside directly in the laboratory, rather than in the hall. At just 45.5 dBA, the TSX Series’ sound level is comparable to a home refrigerator.*
V-drive’s adaptive control is designed to detect usage patterns such as door openings when a higher compressor speed is needed and periods of stability where the compressor runs at a lower speed, saving energy without compromising protection
Wireless Monitoring Solution
Thermo Scientific™ DeviceLink™ comes embedded in your ULT freezer providing real-time monitoring of system status and sample temperature.
View critical lab equipment data and equipment notifications on your mobile and web applications.
Display temperature
Ambient temperature
Alarm and alerts notification
Access data anytime, anywhere—data and alarms from monitored lab equipment are securely stored on the Cloud and sent to the user via email and mobile-phone notifications
InstrumentConnect™ streamlined dashboard-style reporting reduces time spent interpreting data
Unlike traditional connectivity methods, DeviceLink™ operates on a client-cloud architecture, requiring minimal IT support
No need to install sensors—the only plug-in is the equipment data port to read the parameters directly from the factory-installed sensors
Applicable Networks: WPA2-PSK, WPA-PSK, WEP, WPA2-EAP-PEAP, WPA-EAP-PEAP
User Friendly
Newly re-designed touch-screen user interface with easy-to-use: set-up wizard, event log, temperature mapping and data downloads via a built-in USB port
Eliminate the need for a separate chart recorder with the touch-screen’s datalogging and temperature mapping features, all exportable via a built-in USB port
Ergonomic design including comfortable door handle, eye-level touch-screen and shelf-level placement that don’t require floor-level loading of racks
Four capacities (400, 500, 600 and 700 2-inch box) to accommodate a variety of storage needs and lab footprint specifications
Compatible with most racking systems including a full range of Thermo Scientific™ racks for boxes, microplates, Thermo Scientific™ Matrix™ and Nunc CryoBank™ tubes
Security features including alarm settings, padlock-compatible doors and optional access card entry
Sustainability
TSX ULT portfolio is ENERGY STAR® certified providing significantly increased energy savings and decreased operational costs
Natural refrigerants and water-blown foam insulation, making the TSX Series compliant with the U.S. Environmental Protection Agency’s Significant New Alternatives Policy (SNAP), the European Union’s F-Gas and other sustainability standards
Manufactured in an award-winning, zero-waste to landfill facility
Lower HVAC costs as a result of less heat emission into the environment
Footnotes:
* Typical freezer data based on internal testing with freezer setpoint at -80°C and ambient temperature at 20°C. Performance data varies across freezer size and electrical specifications
Full specifications
Green Features Energy Efficient
Product Line TSX Series
Compressor V-Drive Compressor
Holds 2 in. Boxes (400)
Insulation Vacuum Insulation Panels (VIP) + Water-Blown Polyurethane Foam (SNAP-compliant)
Material Polyurethane Foam (Insulation), Stainless Steel (Interior)
Monitoring Options Alarm, Recorder
Rack Capacity 8
Shelves 3
Style Upright
Description TSX Series Ultra-Low Freezers, 400-Box Capacity, 115V, 60Hz
Temperature Range -50°C to -86°C
Certifications/Compliance cULus
ENERGYSTAR
Capacity (English) 19.4 cu. ft.
Capacity (Metric) 549 L
Vial Capacity 40,000 x 2 mL
Electrical Requirements 115 V 60 Hz
Voltage 115 V
Frequency 60 Hz
Amperage 9.0/15 A
Plug Type NEMA 5-15
Dimensions (D x W x H) Interior 28.3 x 23.1 x 51.2 in. (71.9 x 58.8 x 130.1 cm)
Weight (English) 573 lb.
Weight (Metric) 260 kg
Shipping Weight (English) 665 lb.
Shipping Weight (Metric) 302 kg
Display Touch-Screen LCD
Refrigerant R290 (1st stage), R170 + R290 mix (2nd stage)
Capacity (English) Shelf 165 lb.
Capacity (Metric) Shelf 75 kg
Smart View Compatibility Smart-Vue Compatible
Warranty Warranty varies by country, please contact us for details
Depth (English) Interior 28.3 in.
Depth (Metric) Interior 71.9 cm
Height (English) Exterior 78 in.
Height (English) Interior 51.2 in.
Height (Metric) Exterior 198.1 cm
Height (Metric) Interior 130.1 cm
Width (English) Interior 23.1 in.
Width (Metric) Interior 58.8 cm
Defrost Manual
Width (English) Exterior 28.3 in.
Width (Metric) Exterior 71.9 cm
Connectivity Thermo Scientific™ DeviceLink™ (Networks: WPA2-PSK, WPA-PSK, WEP, WPA2-EAP-PEAP, WPA-EAP-PEAP)
Dimensions (DxWxH) Exterior 37.6 x 28.3 x 78 in. (95.5 x 71.9 x 198.1 cm)
Depth (English) Exterior 37.6 in.
Type Ultra-Low Freezer, Upright
Depth (Metric) Exterior 95.5 cm
Unit Size Each
